Radartechnologie

Car radar technology - a lifesaver goes into series production

Dipl.-Ing. Ralf Bornefeld (Spokesperson)
Dr.-Ing. Walter Hartner
Dr. rer. nat. Rudolf Lachner
Infineon Technologies AG, Munich and Regensburg

(f.l.t.r.) Dr. rer. nat. Rudolf Lachner, Dipl.-Ing. Ralf Bornefeld, Dr.-Ing. Walter Hartner

Driving has become increasingly safer over the past few decades. Yet several thousand traffic accidents still result in severe or fatal injuries every year in Germany. How can the number of accidents be reduced?

Dipl.-Ing. Ralf Bornefeld, Dr.-Ing. Walter Hartner and Dr. rer. nat. Rudolf Lachner have the answer: Introduce active safety systems that automatically intervene if an accident is imminent. The three researchers have laid the foundation for cost-efficient manufacturing of these types of systems, making them affordable for small and medium class cars. They introduced two innovations: a manufacturing technology for radar chips based on silicon and silicon-germanium (SiGe) as well as a packaging technology. The three nominees are employed at Infineon Technologies AG: Ralf Bornefeld heads the Sensors for Automotive Applications division, Rudolf Lachner is responsible for the development of silicon-based millimeter wave technologies, Walter Hartner is Project Manager for eWLB packaging technologies.

A number of passive safety systems which have gradually been included in cars since the 1970's - like ABS, airbags and side airbags - have reduced the number of traffic accident-related injuries and fatalities. It is hoped that active systems will now continue this trend. They are capable of recognizing pedestrians, detecting blind spots, warning drivers if they fail to maintain enough distance from other vehicles and even apply the brakes in an emergency. Each of these functions is made possible by radar sensors: These contain microchips that send and receive electromagnetic millimeter waves in the frequency range of 77 Gigahertz. Driver assist systems using radar function safely and reliably in the dark, inclement weather or when visibility is poor due to dazzling. In the past, these radar systems have been so expensive that they were only installed in premium-class vehicles.

But the Infineon researchers have changed all this with their innovations. Instead of choosing gallium arsenide which is the material commonly used in semiconductor production, they opted for silicon and silicon germanium. This allowed them to make use of proved and tested manufacturing technologies long applied in the large scale production of processors and memory for cell phones or computers. This considerably lowers the cost of manufacturing radar systems - and makes a higher integration possible: the sensor's send and receive functions can now be consolidated in a maximum of two radar chips.

Researchers also adapted a packaging technology to the stricter requirements in the radar high-frequency range which in the past were only able to be used for mobile service applications. With the optimized eWLB technology (embedded Wafer-Level Ball Grid Array) Infineon can integrate radar chips in a robust package prior to delivery which makes further processing easier and less expensive for car system manufacturers.

The combination of both innovations is a breakthrough for radar in the automotive sector. Sensors for active safety systems can thus be manufactured so affordably that they are now also attractive to small car buyers. Within a few years of the introduction of the new manufacturing and packaging technology, they will be available as equipment extras for vehicles of all classes. Affordable radar sensors will also stimulate the development of autonomous vehicles that are capable of driving, steering and parking without driver intervention. Reliable active systems are essential for the safety of autonomous self-driving cars.

Radar technology is of great economic importance: experts from the Strategy Analytics market research institute expect the market for radar sensors to increase by around 4 percent per year over the next few years. Infineon stands to profit - thanks to a technical advantage over the competition. This reinforces Germany's status as a manufacturing center because it is home to most of Infineon's research and development, but also to the manufacturing of the radar chips.

The right to nominate outstanding achievements for the Deutscher Zukunftspreis is incumbent upon leading German institutions in science and industry as well as foundations.

The project "Car radar technology - a lifesaver goes into series production" was nominated by the German Patent and Trademark Office.

more details

Resumes

Dipl.-Ing. Ralf Bornefeld

Dipl.-Ing. Ralf Bornefeld

01.02.1964
Born in Schalksmühle, North Rhine-Westphalia, Germany
1983
Abitur (German university entrance qualification)
1983 - 1992
Studying Electrical Engineering at the Technical University of Dortmund (TU Dortmund University), Germany
1991 - 1992
Diploma thesis at Elmos Semiconductor GmbH in Dortmund
1992 - 1995
Development engineer for semiconductor technologies, Elmos Semiconductor GmbH, Dortmund
1995 - 1997
Head of technology development, Elmos Semiconductor GmbH, Dortmund
1997 - 2002
Head of research and development, Elmos Semiconductor AG, Dortmund
(Since 1999, Elmos Semiconductor is listed on the stock exchange)
2002 - 2004
Business unit head „Mechatronik/Sensorik“, Elmos Semiconductor AG, Dortmund
2005 - 2007
Head of process integration, Infineon Technologies AG, Regensburg, Munich and Villach (Austria)
2007 - 2008
Head of technology, Infineon Technologies AG, Regensburg
2008
General Management Program, Harvard Business School
2008 - 2011
Head of development „Sense&Control“, Infineon Technologies AG, Munich
since 2011
Business unit head „Sense&Control“, Infineon Technologies AG, Munich

Dr.-Ing. Walter Hartner

Dr.-Ing. Walter Hartner

02.01.1968
Born in Lauingen/Danube, Germany
1987
Abitur (German university entrance qualification)
1989
Start of Academic Studies, Physics, Friedrich-Alexander-University in Erlangen-Nürnberg, Germany
1991 - 1992
Erasmus Scholarship at the Imperial College in London, England
1993 - 1994
Master Thesis: „Scanning Tunneling Microscopy of Silicon Carbide“
1995
Master of Science Degree in Physics
1995 - 2000
Development engineer for integration of ferroelectric memories (FeRAM), Siemens AG, Munich
1996 - 1997
Delegation, development cooperation and technology transfer ferroelectric materials, Siemens AG and Symetrix Corp., Colorado Springs (Co) USA
2001 - 2003
Lead-engineer and module owner for Shallow Trench Isolation (STI) for 180nm and 110nm DRAM memory technologies, Infineon Technologies AG, Richmond (VA) USA
2003
Ph.D degree by Prof. Dr. Rainer Waser at the RWTH Aachen, Germany; Dissertation title: „Formation and Characterization of SrBi2Ta2O9 (SBT) Thin Film Capacitor Module“
2003 - 2009
Lead-engineer for the introduction and integration of a novel Deep Trench Isolation (DTI) for different Smart Power Technologies (SPT) for the automotive market, Infineon Technologies AG, Regensburg, Germany
since 2009
R&D project manager for the eWLB-Radar Package Technology for the automotive market, Infineon Technologies AG, Regensburg, Germany

Dr. rer. nat. Rudolf Lachner

Dr. rer. nat. Rudolf Lachner

25.02.1952
Born in Parsberg/Oberpfalz, Bavaria, Germany
1971
Abitur (German university entrance qualification)
1971 - 1978
Studying physics at the Technische Universität München (TUM, Technical University Munich)
1978
Received diploma degree in physics from the Technische Universität München (TUM)
1978 - 1984
Scientific assistant at the Technische Universität München (TUM), Institute of Physical Chemistry
1984
Received Dr. rer. nat. degree from the Technische Universität München (TUM)
since 1984
Siemens AG, Semiconductor Group, Munich, Germany.
The Semiconductor Group of Siemens was spun off in 1999 to operate under the name Infineon Technologies AG, Munich, Germany.
1984 - 1989
Development engineer for high frequency processes and analog/mixed signal bipolar processes
1990 - 1996
Head of bipolar and BICMOS technology development
1997 - 2003
Department head for technology development within the Wireless Communications division
since 2004
Responsible for radar technology development within the business unit „Sense & Control“ and program manager
since 2005
Senior Principal „Radio Frequency Technology“
Overall project leader of large national and international funding projects, such as KOKON, ROCC, DOT5, and DOT7

Contact

Spokesperson

Dipl.-Ing. Ralf Bornefeld
Infineon Technologies AG
Am Campeon 1-12
85579 Neubiberg
Phone: + 49 (0) 89 / 23 42 81 85
E-Mail: ralf.bornefeld@infineon.com
www.infineon.com

Press

Monika Sonntag
Infineon Technologies AG
Am Campeon 1-12
85579 Neubiberg
Phone: +49 (0) 89 / 23 42 44 97
Mobile: +49 (0) 170 / 22 13 280
E-Mail: monika.sonntag@infineon.com
www.infineon.com

A description provided by the institutes and companies regarding their nominated projects

Driving has become increasingly safer over the years, and radar technology is the next leap forward. The last few decades have already seen a considerable decline in the number of road traffic accidents that result in severe or fatal injuries. This trend began with the introduction of passive safety systems such as ABS (anti-lock brake system, 1978), frontal airbags (1980), and side airbags (1996). Now, active safety systems are bringing further advances. These systems warn the driver or actively intervene in the driving process, so avoiding or minimizing the effects of a crash. Examples of this type of safety system include pedestrian detection, distance warning and blind spot assist. Many of these active safety systems employ radar technology in the form of chips that send and receive electromagnetic waves in an extremely high frequency range. Compared to other, mostly camera-based, driver assistance technologies, radar functions reliably even under difficult visibility conditions caused by snow, fog, heavy rain or dazzling backlight.

The democratization of safety
Mercedes Benz first installed a distance radar system in the year 1998, in its S-Class range. At that time, the costs for manufacturing the necessary high-frequency components were extremely high. What's more, the material required for the semiconductors was expensive and difficult to process. The upshot of this was that radar technology was initially restricted to premium-class vehicles. Even at the time, Infineon was convinced of the potential of this technology for enhancing active safety, and spent years researching new solutions that would overcome the technical constraints of the time. Eventually, two innovations led to a breakthrough: the manufacture of silicon germanium-based (SiGe) sensor chips and use of the new eWLB packaging technology. Thanks to these innovative manufacturing processes, radar systems became affordable for all drivers. A technology that was previously reserved for the owners of premium vehicles thus came to be used for active crash prevention in cars of all classes. In the meantime, emergency brake assist systems are available as inexpensive optional extras even in small cars, often costing less than a metallic finish.

Simpler and more cost-effective: manufacturing using silicon germanium (SiGe)
Radar operates on the basis of high-frequency electromagnetic oscillations sent out as millimeter waves. 77 Gigahertz (GHz) radar technology processes 77 billion oscillations per second, that's over 30 times more than the highest frequencies used in mobile communications. Up to 2009, only semiconductors based on gallium arsenide (GaAs) were able to process frequencies as high as this. However, the manufacturing processes for GaAs chips are far less mature than those for silicon-based chips and therefore more expensive. A further disadvantage is the lower level of integration, i.e. fewer functions can be placed on the surface of GaAs chips. In 2009, after many years of R&D work, Infineon became the first company able to offer highly-integrated circuits for this frequency range based on silicon and silicon germanium (SiGe) – the materials most frequently used for semiconductor manufacturing. This made it possible to employ the same sort of standard production techniques as are used for the mass manufacturing of memory, logic and microprocessor components. What's more, instead of the eight GaAs chips previously required, the Infineon team was able to compress a wide range of the radar module functions onto a maximum of two SiGe components. This innovative leap opened the door to a mass market.

Lateral thinking: compact eWLB packaging simplifies the further processing of components
The next decisive breakthrough was the idea of applying chip package technology from the mobile communications domain to car radar – eWLB (embedded Wafer-Level Ball Grid Array). At first, industry experts were not convinced that the eWLB technology would be able to meet the automotive sector's high reliability requirements. The Infineon team, however, remained optimistic and continued with their research work, funded by the German Federal Ministry of Education and Research. Eventually, in close collaboration with the customer Bosch, a solution was found. Today, instead of delivering the “naked” chip, Infineon encloses it in a robust package. The benefits for the customer are two-fold. Firstly, the component is eminently capable of meeting the requirements in the high frequency range. Secondly, the system supplier of radar systems can use inexpensive standard techniques for further processing of the radar chips. All in all, maximum performance at a minimum overall cost.

Developed and manufactured in Germany – successful in markets around the world
Further development of the SiGe and eWLB technologies for use in radar systems has given Infineon a competitive lead of around two to three years over its rivals in the USA and Asia. R&D work for these technologies was performed in Munich, Regensburg, and Dresden in Germany as well as in Linz in Austria. The radar systems themselves are manufactured entirely in Germany. All stages of the process – from chip manufacturing to processing in the package – are carried out at Infineon's plants in Regensburg and Dresden. These facilities are able to offer the quality necessary for car safety systems and, at the same time, keep the costs as low as possible thanks to innovative manufacturing processes.

The SiGe and eWLB technologies have enabled radar systems to move from the premium segment to the vehicle mass market. Demand is now growing worldwide: the market for 77 GHz radar systems has jumped from around half a million in 2009 to approximately 7 million in 2015. By 2020, market analysts expect demand to climb to around 19 million systems.

Radar systems make cars safer and more efficient. After systems that assist drivers, the next step is the deployment of autonomous driving solutions, in which radar systems will also play a critical role. In January 2015, an Audi A7 completed the journey between San Francisco and Las Vegas practically without the intervention of a driver. 150 self-driving Google cars are already on the road, and gathering practical experience – Using radar technology from Germany.
